Drilling series
> >
HY5124
HY5124
Contact UsRequest a quote
Share This Product:
  • Specifications

Model

SP5124

Max.twist drill bit

Φ23mm

Max. Hole drill capacity

Φ55mm

6 gears of electronic speed control

200-550r/min

Max taper

M22

Max cutting stroke

190mm

Min.steel plate thickness

10mm

the magnet strength

＞15000N

Spindle inner hole taper

MT2

Voltage

220~230V/110V~120V

Rated frequency

50HZ/60HZ

Rated input power

1500W

6 gears of electronic speed control

200-550r/min

N.W

23kg

Number Picture

Chuck guard

Front  switch

Keyless drill chuck

Key type drill chuck

Vice

Laser
